Which part is splined to the clutch disc?
a. Main shaft
b. Countershaft (lay shaft)
c. Cluster shaft
d. Main gear
The correct answer and explanation is:
Correct Answer: a. Main shaft
Explanation:
The main shaft is the part of the transmission that is splined to the clutch disc, allowing power transfer from the engine to the transmission system. It plays a crucial role in transmitting torque from the engine to the vehicle’s wheels.
Understanding the Clutch Disc and Main Shaft Connection:
- Splined Connection:
- The clutch disc has a hub with internal splines that fit precisely onto the external splines of the main shaft.
- This splined connection ensures that the clutch disc and the main shaft rotate together, effectively transmitting power.
- Function of the Main Shaft in Power Transmission:
- The main shaft extends from the clutch assembly into the gearbox.
- It carries the rotational force from the clutch to the gears inside the transmission.
- When the clutch pedal is engaged (pressed), the connection between the engine and the main shaft is temporarily broken, allowing for smooth gear shifts.
- Role in Gear Engagement:
- The main shaft is responsible for transferring power to different gears selected by the driver.
- As gears engage and disengage, the speed and torque transmitted to the wheels change accordingly.
- Comparison with Other Shafts:
- Countershaft (Lay Shaft): It is connected to the main shaft through gears but does not directly connect to the clutch.
- Cluster Shaft: This is another name for the countershaft, which carries multiple gears.
- Main Gear: It is not a specific part related to clutch connection.
Thus, the main shaft is the only part that is splined to the clutch disc, making it the correct answer.
